Available courses

CARRY OUT CIVIL ENGINEERING WORKS I

Carry Out Civil Engineering Works I is a unit that equips trainees with the knowledge, practical skills, and competencies required to undertake basic civil engineering and construction activities according to standard construction procedures and occupational safety requirements.

The unit focuses on three major areas:

  1. Site Preliminary Works – involving surveying construction sites, preparing site layouts, determining boundaries, hoarding/screening sites, clearing sites, constructing site utilities, and preparing preliminary reports.
  2. Building Temporary Works – involving the construction and dismantling of temporary structures such as timbering, formwork/shuttering, scaffolds, and shores used to support construction activities safely.
  3. Substructure Works – involving setting out civil engineering structures, excavating foundations, laying foundations, erecting foundation walls, and constructing solid ground floors.

The unit also emphasizes:

  • Proper use of construction tools and equipment,
  • Interpretation of technical drawings,
  • Measurement and setting out,
  • Occupational safety and health (OSH),
  • Environmental conservation practices,
  • Teamwork and communication in construction projects.

The competencies gained enable trainees to participate effectively in civil engineering and building construction projects while observing quality standards, safety regulations, and professional work procedures.

SITE SURVEY

URVEY IN BUILDING TECHNOLOGY – NOTES

1. Definition of Surveying

Surveying is the science and art of determining the relative positions of points on, above, or below the Earth’s surface using measurements of distance, angles, and elevation.

2. Purpose of Surveying in Building Technology

  • To determine land boundaries

  • To prepare maps and plans

  • To set out buildings and structures

  • To calculate areas and volumes

  • To assist in construction and design

3. Types of Surveying

a) Plane Surveying

  • Assumes the Earth is flat

  • Used for small areas

  • Common in building projects

b) Geodetic Surveying

  • Considers Earth’s curvature

  • Used for large-scale projects

4. Types of Surveys

  • Topographical Survey – Shows natural and man-made features

  • Cadastral Survey – Defines land ownership and boundaries

  • Engineering Survey – Used for construction projects

  • Route Survey – For roads, railways, pipelines

  • Levelling Survey – Determines height differences

5. Basic Surveying Instruments

a) Chain / Tape

  • Used for measuring distances

b) Compass

  • Measures directions (bearings)

c) Theodolite

  • Measures horizontal and vertical angles

d) Level (Dumpy Level)

  • Used to determine elevations

e) Total Station

  • Electronic instrument combining angle and distance measurement

6. Chain Surveying

Principles

  • Work from whole to part

  • Fix main control points first

Key Terms

  • Baseline – Main survey line

  • Offset – Perpendicular distance from baseline

  • Tie Line – Used for checking accuracy

7. Levelling

Purpose

  • To determine height differences between points

Types

  • Simple Levelling

  • Differential Levelling

  • Profile Levelling

Common Terms

  • Benchmark (BM) – Reference point with known elevation

  • Back Sight (BS) – First reading taken

  • Fore Sight (FS) – Last reading before moving instrument

  • Intermediate Sight (IS) – Any other reading

8. Traversing

  • A method of surveying using connected lines

  • Can be:

    • Open Traverse – Does not return to start point

    • Closed Traverse – Forms a loop

9. Errors in Surveying

Types of Errors

  • Systematic Errors – Predictable and correctable

  • Random Errors – Occur due to small variations

  • Gross Errors – Mistakes (e.g., wrong readings)

Sources

  • Instrument errors

  • Human errors

  • Natural factors (wind, temperature)

10. Setting Out in Construction

  • Transferring building design from drawings to the ground

  • Ensures correct position, level, and alignment

Steps

  1. Establish reference points

  2. Mark foundation lines

  3. Use pegs and profiles

  4. Check measurements

11. Modern Surveying Technology

  • GPS (Global Positioning System)

  • Drones (UAVs)

  • GIS (Geographic Information Systems)

  • Laser scanning

12. Safety in Surveying

  • Wear protective gear (helmet, boots, reflective vest)

  • Be aware of surroundings

  • Handle instruments carefully
